High Light
High Speed Roll Punching Machine
,1300mm roll punching machine
,Paper Cup punching machine CQ850
-
Name1300mm 150-200 Times/min 10kw Paper Cup High Speed Roll Punching Machine
-
Oil LubricationManual
-
Voltage380V±
-
Power10kw
-
Cutting Speed150-200 Times/min
-
Dimension3000x1400x2000mm
-
Place of OriginHenan, China
-
Brand NameFECT
-
CertificationCE
-
Model NumberCQ850
-
Minimum Order Quantity1 set
-
PriceUSD$ 19841.00/set
-
Packaging DetailsExport-standard and sea-worthy wooden case.
-
Delivery TimeWithin 35 days after deposit received
-
Payment Terms30% T/T as deposit in advance, the balance by T/T after production
-
Supply Ability20 Set/Sets per Month 850 paper cup blank printing die cutting machine
1300mm Paper Cup High Speed Roll Punching Machine CQ850
1300mm 150-200 times/min 10kw paper cup high speed roll punching machine
♦Features♦
1. Each printing unit have one IR drier
2. Each printing unit adopt 360 for registration
3. Adopt the anilox roller to spread ink
4. The main motor is adopted the import stepless, regulation of frequency conversion
5. Unwinding and rewinding are controlled by magnetic power brake, clutch (or by automatic tension controller of Mitsubishi, made in Japan)
6. Unwinding, web guiding, printing, IR drying, die-cutting, waste, rewinding, trimming, rewinding, can be finished in one process
7. The rubber roller can break away automatically while parking, and running at alow speed, in order to avoid ink being ary.
Product Description
This CQ850 paper cup blank punching die cutting machine is fully automatic with paper feeding, cutting and rewinding function.
♦Application♦
This is an ideal machine for paper cup, paper bowl factory to cut many kinds of the paper cup, coffee cup, paper bowl, paper box, etc.
♦Technical parameters♦
| Cutting speed | 150-200 times/min |
| Max. web width | 860mm |
| Max. unwind diameter | 1300mm |
| Max. cutting size | 850mmX450mm |
| Precision | ±0.15mm |
| Voltage | 380V± |
| Power | 10kw |
| Oil lubrication | Manual |
| Weight | 3000kg |
| Dimension | 3000x1400x2000mm |
Packaging Details
Wooden Case/ 850 paper cup blank punching die cutting machine
| Package detail | Wooden case/ paper cup blank printing die cutting machine |
| Package size | 39m×18m×2.2m |
| Gross weight | 3500kg |
When you purchase machines, high-quality products, good service and favorable price should be your consideration. Most importantly, a reliable supplier will help you solve it, so chose us.
We have won the trust and support from customs home and abroad. In order to provide better products and service, our company emphasis on the recruit of the international talents and has abundant technical power. It is well-worth mentioning that we always follow the principle:to serve our customers with a high sense of responsibility.Our workers are all high-motivated and our engineers take care of every detail and adopt strict factory quality standard with the philosophy "God is in the details
FAQ
Q: Do you factory accept customized configuration?
A: Yes. About electric parts, you could choose SIEMENS, Schneider, Delta and etc. For the machine device, web guiding, video monitor, pneumatic-unwinding loader,electric-rewinding unloader, slitting station rotary die-cutting station, lamination and waste rewinding are optional. For the specific combination, pls contact us.
Q: How does your factory do regarding quality control?
A: Quality is the priority. We always regard great importance to quality controlling from the very small thing (even a small screw we will choose the best quality) from the beginning.
Q: What is your after-sales service?
A: Our after-sales service is first class. We have a powerful team to help you solve problems. The Warranty is one year and if the machine is damaged by natural, not by a human, we can send the new parts to you for free.
Q: What are the terms of payment you accept?
A: 30% T/T in advance, 70% T/T balance before delivery. We also accept L/C and Western Union.
Our products are sold all over the world, you can rest assured.
