180pcs/min Food Meal Disposable Paper Carton Box Erecting Forming Machine
♦ Technical Specification ♦
1. Automatically counting , stacking and collecting .
2. Install additionally counter according to the requirements of customers.
3. Adopt glue bonding system to produce aluminum foil and double PE coated paper boxes, one machine can produce various products in a short time.
4. PLC system can control and produce complex boxes, and automatically stop when there is paper jamming or no paper, safer and more convenient for operation.
(1) It can change related wooden mold according to different box. Client need to provide us all of the samples of box.
(2) Water-based adhesive is belongs to food-grade. It is safe for human body.
(3) All of the molds are made of Pine materials, so that can be more durable.
(4) Automatically collecting. According to clients’ request, we can add calculator for
counting the amount of boxes and set a mark per 100/200 boxes in order to counting easily.
(5) PLC control system, during running period, the machine will stop automatically when
short of paper, become more safety for operator.
Use water-based adhesive coat the roller by foam, and apply on the paper glue position.
2. Paper feeding
The feeding part adopts mechanical rubber-wheel paper feeding structure, which can feeding paper in any size and specification without adjust in addition. The machine adopts chain drive to guarantee smooth running, hard-wearing. the chain drive of every unit are separated to reduce noise and workload, increase the stability ,The transmission width can be adjusted by the screw rod easily and Conveniently.
3. Forming device and box collector
The mold height is adjustable and can be made into various specifications and shapes, such as the taper box and flapped hamburger box etc. Automatic counter can be set mark 100/200pcs one time for paper box subgroup packing. The size of the box collecting frame can be adjusted by hand wheel simple and convenient. When change the mold the frame can be opened, more convenient to adjust the position of hook.
♦Technical Specification ♦
|Voltage||220V 50Hz ( at customer requirements)|
|Box Angles||5°- 40°|
|Edge banding height||H 15-200mm|
|Occupancy of machine||1.2m*4m|
|Bonding/Gluing device||Water-based adhesive|
|Paper thickness||Max 1.5mm (120g-450g)|
|Package measurements||3.55m*1.35m*1.7m (L*W*H) (8.76CMB)|
|Compressor (optional)||0.5-0.6Mpa, 1 CBM volume|
|Package detail||Export wooden case/Automatic pastry burger take away food box making machine|
|Package size||3.55*1.35*1.7 m|
Automatic pastry burger take away food box making machine use thermal bonding system to produce various fast food paper box container with high quality and efficiency.
PLC control system can produce various complex boxes, and automatically stop when there is paper jamming or no paper, more safe and convenience for operation.
Automatically collecting, stacking and counting (optional).
Automatic pastry burger take away food box making machine is a special forming machine that produces various fast food box container, such as, burger box, one block box, food pail box( take away box), hamburger box, French Fries box take out container and other related containers made by aluminum foil paper and double PE coated paper.
Q1: Are you manufacturer or trading company?
A: We have our own factory and export team, we not only provide machines, more importantly, we provide solutions based on your detail needs, welcome to visit our factory, we can pick you up at the airport.
Q2 : What quality certificates you have?
A: Yes, so far, we have CE, ISO, etc. we also can issue CO, Form E, etc if you need.
Q3: Do you inspect the finished machines?
A: Yes, we have QC department,they will inspect every machine before packing and provide test video to ensure there is nothing problem of the machines.
Q4 : What payment terms are accepted?
A: Usually we appreciate TT(Telegraphic Transfer) 30% deposit , then 70% balance paid before shipment, .L/C , Western Union, MoneyGram is also available ,and do CFR&CIF etc.
Q5 : When can the machine be shipped after order is placed?
A: Around 20~30 days, it depends on machine model and quantity, some stock machines can be shipped within 3 working days after payment, other customized machines start production after deposit arrived, please contact our staff for detail info.
Q6: How about the warranty and after-sale service?
A: Our machines have two years warranty and lifetime technical support. Help is always just one call or email, and then we can provide a suitable solution within 8 hours after analyzing and estimating the problem. Remote training and engineer distributed to overseas is available.
