14kw 4-16 oz 140-170 pcs/min Full Automatic Paper Cup Forming Machine
PF-OC100 features full servo driven technology throughout the entire machine. Servo drives work independently to control each station with remarkable accuracy and work together to coordinate the synchronized motion. It replaced the market almost gear / chain transmission and cam design paper cup machine. It provides flexibility, speed, affordable capital cost and low maintenance.
|Cup size:||4-16 oz (other customized size)|
170-380 gsm single or double PE/PLA/ coated paper
aluminum foil paper
|Production capacity||140-170 pcs/min|
380V 3- phase 50HZ 34kw
Running consumption is 14kw
(please inform us your power in advance)
|Air Supply||0.6 Mpa,(running consumption 0.4Nm3/min)|
|H.S code for customs||8441309000|
♦ Advantage ♦
Paper cup bottom and top forming driven mechanism
Adopts crankshaft and servo motor control instead of traditional cam transmission, no oil lubricant, which solved the negative effects of cam and bearing wearing and impacting while machine running at high speed. This breaks through the traditional paper cup machine must using cam to control the lifting and time.
Paper cup bottom sealing process
PF -150 changed the working procedure of bottom sealing. First Leister hot air preheating the cup body, then the cup bottom paper coming. This procedure makes fast sealing while the hot and cold paper touched each other. Then the second Leister hot air heating the bottom to go next knurling process. It makes the paper cup bottom seal more firmly while machine running at high speed. Traditional paper cup machine they do the double bottom heating after bottom paper come to the cup body. PF -150 new design makes the bottom knurling much better.
Paper cup servo indexing mechanism
PF -150 uses servo indexing mechanism, replaced the traditional paper cup machine which uses the Geneva indexing mechanism. It's new in paper cup machine manufacture field. Servo indexing mechanism no need oil lubricant, no need maintenance, easy installation. It is more flexible for the machine self- adjustment while machine change the speed, even machine working in worse running conditions.
Paper cup blank shuttle& rotary placer mechanism
PF -150 adopts the most advanced blank shuttle & rotary placer mechanism, replaced traditional up and down movement suction feeding way to avoid paper move problem. Rotary placer mechanism pick and put paper more stable, which ensure the paper feeding to cup body sealing part more smoothly and steady.
|Medium PLC (AM403-CPU1608TN+ module)||Inovance|
|10-inch touch screen||Inovance|
|EtherCat network cable (CAT6A industrial grade)||Customize|
|Power switch||Taiwan MEAN WELL|
|Steam source pressure protector||Autonics|
|Circuit breaker||Schneider, France|
|AC contactor||Schneider, France|
|Small relay (including base)||Izumi, Japan|
|Terminal block||Phoenix, Germany|
|Power phase sequence protector||Semute|
Stable wooden package protects machine from strike and damage.
Wound plastic film keeps machine out of damp and corrosion.
Fumigation-free package helps the smooth customs clearance.
The big size machine will be fixed in container without package.
We elaborate every product to provide customers with the best service.
We have rich experience to provide customers with the best products and services.
We have a professional team which can well feed customers to solver problems and provide better services.
When you purchase machines, high-quality products, good service and favorable price should be your consideration. Most importantly, a reliable supplier will help you solve it, so chose us.
We have won the trust and support from customs home and abroad. In order to provide better products and service, our company emphasis on the recruit of the international talents and has abundant technical power. It is well-worth mentioning that we always follow the principle:to serve our customers with a high sense of responsibility.Our workers are all high-motivated and our engineers take care of every detail and adopt strict factory quality standard with the philosophy "God is in the details
Quality Guarantee: One year warranty and lifelong technical service, Inspection before delivery is available. The above clause is ONLY effective under the machine is being properly used, any artificial misuse or destroy purposely is not within the limit of Quality Guarantee.
Installation and Debugging: we can send technician for installation and training at the cost of buyer (visa, round tickets, eating, accommodation in his country and salary 120 USD /day).
