Packaging Length Unlimited Automatic plastic cup paper cup packing machine
Automatic plastic cup paper cup packing machine is an automatic unmanned packaging machine. It is widely used in mass production and packaging. It has high work efficiency, automatic film feeding and punching, automatic film sealing and cutting, and automatic winding of waste; only manual adjustment of the film guide system and Manually adjust the feeding and conveying platform, suitable for products of different widths and heights. It can be used in conjunction with an automated packaging line and is the first choice for product sealing and heat shrink packaging.
♦Technical parameters♦
Model | PBF450 | PBF550 | PBF650 |
Power supply | 220/50-60HZ | 220/50-60HZ | 220/50-60HZ |
Use air source | 5-7. | 5-7. | 5-7. |
power | 1.35KW | 1.5KW | 1.65KW |
Packing speed | 15-30bags/min | 15-30bags/min | 15-30bags/min |
Maximum packaging size L | Unlimited | Unlimited | Unlimited |
Maximum packaging size W | <400mm | < 500mm | < 600mm |
Sealing and cutting size | Unlimited | Unlimited | Unlimited |
Machine size | 1650x800x1450mm | 1750x900x1450mm | 1850x1000x1450mm |
Total Weight | 300kg | 350kg | 400kg |
Applicable shrink film | POF.PE | POF.PE | POF.PE |
♦Advantage♦
1.Automatic feeding and automatic adjustment. Equipped with induction motor to automatically take up waste.
2.When the size of the package changes, the adjustment is very simple, without changing the mold and bag maker.
3.Products of different sizes can also be combined with packaging to achieve promotional effects.
4.The whole set of machines is truly connected to the unmanned operation of the production line.
5.Specially designed film up and down synchronization mechanism to correct film deviation.
6.The sealing knife adopts DuPont Teflon-coated anti-sticking and high-temperature aluminum alloy knife,and the sealing will not crack, coking, smoke and zero pollution.
♦Details♦
Application
After Sale Service
1) 1 year warranty service.
2) Free replacement of parts within 1 year (free shipping).
3) Parts are provided free of charge within 2 years, but no free shipping.
4) We provide Operation & Maintenance CD.
5) When there is a problem with the machine, please take a video of the problem and send it to us.
6) We will arrange professionals to help you deal with it through video or document tutorials.
RFQ
Q1: Are you a manufacturer or a trading company?
A: We have our own factory and export team, welcome to visit our factory, we can pick you up from the airport
Q2: Do you have relevant certificate?
A: Yes, so far we have CE, ISO, etc. We can also issue CO, Form E etc. if you need it.
Q3: Do you inspect finished machines?
A: Yes, we have QC department, they will inspect each machine before packing, and provide testing video to make sure there is no problem of the machines.
Q4: What payment terms are accepted?
A: TT (Telegraphic Transfer), Western Union, MoneyGram, LC, etc.
Q5: When can the machine be shipped once the order is placed?
A.It depends on the machine model and quantity, some machines in stock can be shipped out within 3 working days after payment is cleared, other customized machines start production after deposit arrives, please contact our team for information detailed.
Q6: What about warranty and after-sales service?
A: Our machines have a two-year warranty and lifetime technical support. Help is always just a call or email away, then we can provide a suitable solution within 8 hours after analyzing and estimating the problem. Remote training and door-to-door service are available.
