4-50 Oz Ultrasonic 45-50 Pcs/Min Coffee Paper Cup Making Machines Hollow Double Wall
-
High Light
50 Oz Paper Cup Making Machines
,50 Pcs/Min Paper Cup Making Machines
,50 Pcs/Min paper coffee cup making machine
-
TypePFD-24
-
Cup Size4-50 Oz (other Customized Size)
-
Production Capacity45-50 Pcs/min
-
Power Source220V/380V 50HZ
-
Suitable MaterialGray Bottom White Paper（200-400g/m2）
-
Total Power4 KW
-
Weight1000KG/1144kg
-
Packing Size2100 X 1250 X 1750 Mm/ 2.35*1.25*1.75 M
-
Place of OriginHenan, China
-
Brand NameFECT
-
Model NumberPFD-24
-
Minimum Order Quantity1 set
-
PriceUSD$ 7000-9000/ Set
-
Packaging DetailsExport-standard and sea-worthy wooden case
-
Delivery TimeWithin 30 days after deposit received
-
Payment Terms30% T/T as deposit in advance, the balance by T/T after production
-
Supply Ability35 sets per month
4-50 Oz Ultrasonic 45-50 Pcs/Min Coffee Paper Cup Making Machines Hollow Double Wall
Automatic Hollow Overcoat Molding Machine of Paper Cup and Bowl is the supporting equipment of Automatic Molding Machine of Paper cup and bowl, with the advanced technology and reasonable design, it has the functions of automatic paper feeding, sealing ,spin coating, error warning, counting and so on.
Overcoat Machine of Paper bowl has two forms of expression: Direct packing overcoat machine and hollow overcoat machine .direct -packing overcoat machine means that the overcoat is directly attached outside of white paper bowl ,without the gap between the inner layer ,with the rolling bottom in the bottom of outside layer, it is more heat-proof than the direct-packing.
♦Technical Specification♦
|
Type
|
PFD-24 |
| Cup size: |
4-50 oz (other customized size) Max. height 120 mm |
|
Production capacity
|
45-50 pcs/min |
|
Power source:
|
220V/380V 50HZ(please inform us your power in advance) |
|
Suitable Material:
|
Gray bottom white paper(200-400g/m2) |
|
Total Power:
|
4 KW |
|
Weight:
|
1000KG/1144kg |
|
Packing size
|
2100 x 1250 x 1750 mm/ 2.35*1.25*1.75 m |
|
Collection device(Optional)
|
0.9*0.9*1.8 m/ 100kg/172 kg |
♦Components brand♦
| Motor |
Main motor
|
JINGGUANG(CHINA) |
| Knurling motor |
SHANGHAI DEDONG(CHINA) |
|
|
educer
|
HANTIAN(CHINA) | |
|
gear box
|
LI ZHONG(CHINA) | |
| Electric elements |
Frequency converter
|
EURO (CHINA) |
|
All other electrical parts
|
CHNT(CHINA) | |
|
Ultrasonic
|
KEJIAN(CHINA) / Ever Green(TAIWAN.CHINA) |
|
|
sensors
|
(CHINA) | |
| Pneumatic | cylinder |
MINGMAN SHAKO (TAIWAN) |
| Bearing |
other bearings
|
(CHINA) |
FAQ
Q1: Are you manufacturer or trading company?
A: We have our own factory and export team, welcome to visit our factory, we can pick you up at the airport.
Q2 : Do you have relevant certificate?
A: Yes, so far, we have CE, ISO, etc. we also can issue CO, Form E, etc if you need.
Q3 : What payment terms are accepted?
A: TT(Telegraphic Transfer), Western Union, MoneyGram, LC, etc.
Q4 : Do you inspect the finished machines?
A: Sure, we test every machine before packing and provide test video.
Q5 : When can the machine be shipped after order is placed?
A: It depends on machine model and quantity, some stock machines can be shipped within 25 working days after payment, other customized machines start production after deposit arrived, please contact our staff for detail info.
Q6: How about the warranty and after-sale service?
A: Our machines have one years warranty and lifetime technical support. Help is always just one call or email, and then we can provide a suitable solution within 8 hours after analyzing and estimating the problem. Remote training and door-to-door service is available.
Our products are sold all over the world, you can rest assured.
